A、旋轉表殼或表殼上的旋鈕可帶動指針旋轉,該指針為記憶指針,稱被動指針或從動指針;和機芯聯接的指針為工作指針,亦稱主動指針。
A. Rotating the case or the knob on the case can drive the pointer to rotate. The pointer is a memory pointer, which is called a passive pointer or a driven pointer; The pointer connected with the movement is the working pointer, also known as the active pointer.
B、使用本產品應根據緊固件的強度等級和扭矩值要求選用量程的規格和型號,不應超范圍使用。表盤式刻度扭矩扳手使用前需調整零位:
B. When using this product, the specification and model of the range shall be selected according to the strength grade and torque value requirements of fasteners, and shall not be used beyond the range. Dial type graduated torque wrench shall be adjusted to zero position before use:
A、右旋使用時:順時針旋轉表蓋上的旋鈕,使記憶指針與主動指針指向刻度盤的零位刻線。
A. Right hand rotation: rotate the knob on the meter cover clockwise to make the memory pointer and active pointer point to the zero mark of the dial.
B、左旋使用時:逆時針旋轉表蓋的的旋鈕,使記憶指針與主動指針靠緊,且主動指針指向刻度盤的零位刻線。
B. Left hand rotation: rotate the knob of the meter cover counterclockwise to make the memory pointer close to the active pointer, and the active pointer points to the zero mark of the dial.
表盤式刻度扭矩扳手使用時注意:將指針扳手的方榫與緊固件對接(根據需要可直接對接,也可通過轉接套筒對接),然后緩慢平穩地施加扳擰力,直記憶指針指向所需的扭矩值。
When using dial type graduated torque wrench, pay attention to: butt the square tenon of the pointer wrench with the fastener (butt directly or through the adapter sleeve as required), and then slowly and stably apply the pulling force until the memory pointer points to the required torque value.
表盤式刻度扭矩扳手使用結束后:表盤式刻度扭矩扳手停止施力后,主動指針在彈性元件和機芯扭簧的作用下自動回復零位,記憶指針仍停留在指示的刻度上,并準確讀出扭矩值。旋轉表蓋上的旋鈕,使記憶指針也回復到零位,可進行下使用。
After the dial type graduated torque wrench is used: after the dial type graduated torque wrench stops applying force, the active pointer automatically returns to zero under the action of elastic element and movement torsion spring, the memory pointer still stays on the indicated scale and accurately reads out the torque value. Rotate the knob on the meter cover to return the memory pointer to the zero position, which can be used in the next step.
